Teradek PRISM 802 Rack 2U | Kit Encoder & Decoder Wired

Teradek - Encoder / Decoder Unit Board Mounting Chassis - 2RU
It is the basis for creating the Prism system, i.e. a solution for broadcast, live production and Pro AV use as a 4K H.264/HEVC encoding/decoding unit
With space available in the standard 2-unit version, it allows you to accommodate a maximum of nine codec cards.
The Prism system can encode or decode video up to 4Kp60 with stunning 4:2:2 10-bit image fidelity while supporting popular streaming protocols such as MPEG-TS,
RTP, RTMPS and SRT.

Product Highlights
° 2RU rack mount chassis for Prism encoder and decoder cards
° Supports up to 9 Prism encoder and/or decoder cards
° Dual gigabit Ethernet ports
° Optional redundant power supply

In The Box
1 x Prism Chassis Base Rack System 2U
1 x Power Cable IEC 10ft black USA
1 x Teradek Standard Terms and Conditions
1 x CORE Booklet
1 x Insert - Product Register
1 x Quickstart Guide - PRISM

Power
Power Supply Removable, redundant power supply
Power Input 2U: 2x Hot-swappable 500W
A/C power inputs 1110 - 220 Vac
Nominal Power Consumption 5W - Up to 15W/card

Network
Ethernet 2x 10/100/1000 Ethernet ports

Phisical Attributes
Dimensions 2U: 17"W x 12.1"D x 3.5"H - [431.8 x 307.3 x 88.9 mm]
Weight 2U: 143oz [4040g]
Construction: Milled/Bent aluminum

1 x Prism Chassis Base Rack System 2U
1 x cavo di alimentazione IEC 10 piedi nero USA
1 x Termini e condizioni standard Teradek
1 x libretto CORE
1 x inserto - Registro del prodotto
1 x Guida rapida - PRISM

PRISM 802 Rack 2U - TeradekEAN 818264025895
