V-Mount Adapter for RED Komodo

V-Mount Battery Plate for RED KOMODO
Mounts onto Camera Dual Battery Plate
Compatible with Vmicro Batteries
1 x 12 VDC Twist D-Tap Output
2 x 12 VDC 2-Pin LEMO-Type Output
1 x 5 VDC USB Type-A Output
1 x 2-Pin LEMO-Type Hot-Swap Input
Allows Battery Hot-Swapping
Durable Aluminum Construction

The Vmicro V-Mount Battery Adapter Plate from bebob offers a lightweight, high-capacity battery solution that mounts a single Vmicro V-mount battery with multiple outputs to simultaneously power your RED KOMODO cinema camera as well as a variety of accessories mounted on your camera rig. The durable aluminum plate mounts onto the dual BP-U plate on the KOMODO and features one unregulated 14.4 VDC D-Tap output, two 12 VDC 2-pin LEMO-type outputs, and one 5 VDC USB Type-A output.

The D-Tap output is a "twist" plug that allows you to plug your D-Tap connector in either direction. The plate also features a 2-pin LEMO-type input to power the plate from an alternate source, allowing hot-swap capability with either mains power or another power source.

Compatibility

RED KOMODO 6K cinema camera
A professional V-mount Vmicro battery

Power Output
D-Tap: 14.4 VDC at 5 A
USB-A: 5 VDC at 1 A
LEMO 2-Pin: 12 VDC at 2 A
Camera Power Method
Connector
Plate Front / Battery Mount
V-Mount
Hot-Swap Support
Yes

Power
Power Input
LEMO 2-Pin: 7 to 17 VDC
Power Output
D-Tap: 14.4 VDC at 5 A
USB-A: 5 VDC at 1 A
LEMO 2-Pin: 12 VDC at 2 A
General
Camera Power Method
Connector
Inputs/Outputs
1x D-Tap
3x LEMO 2-Pin
1x USB-A
Plate Front / Battery Mount
V-Mount
Number of Battery Bays
1
Hot-Swap Support
Yes
Material of Construction
Aluminum
Dimensions
3.2 x 2.6 x 1" / 82.2 x 66 x 26.1 mm
Weight
7.9 oz / 225 g
Packaging Info
Package Weight
0.595 lb
Box Dimensions (LxWxH)
5.3 x 4.7 x 2.5"
