MGX12 B - Yamaha

Audio Mixer > Digital mixer
€ 614,00 + VAT
€ 749,08 VAT Included
Adcom - Yamaha
New
Availability: 1 unit
Yamaha 18-Channel Digital Mixing Console with Audio Interface - 16x Input / 8x Output (Black)

- For Live Sound, Podcasts, and Streaming
- 4 Combo XLR-1/4" Mic/Line Inputs
- 4 1/4" & RCA Inputs + XLR & 1/4" Outputs
- Dual USB: 18x18 Rec/Play + 2x2 Rec/Play
- Bluetooth Audio Input, MicroSD Recording
- Customizable Sound Pads
- Smart Gain + Studio Quality FX
- Built-In Compression and EQ per Channel
- Four Headphone Outputs
- Includes Expansive Software Library


The MGX12 B 18-Channel Digital Mixing Console from Yamaha builds on the legacy of the well-established and appreciated MG series, adding digital capabilities and a host of features that make it a great choice for live and installed sound, podcast/live streaming, recording, production, and many more audio/video applications.

Designed to be operated quickly and intuitively through its touch-panel GUI with 4.3" Touchscreen with 5 Control Knobs, a comprehensive selection of I/O options allow the user to design the system from the bottom up for any usage purpose.
Sound quality is bolstered by MGX preamps with 86 dB of gain range, and an included software bundle that features studio mainstays Cubase, Wavelab, and more.
Ensure your event goes off as smoothly as possible with assistive additions like Automix, Clip Safe, and scene recall.
Whether in clubs, convention centers, or houses of worship, the MGX quickly accommodates a wide range of audio and video production situations, with the quality and durability that users expect from Yamaha.
Mixer
Max I/O Capacity: 16x Input / 8x Output
Number of Analog Input Channels: 16
Number of Mic Preamps: 4
Number of Analog Output Channels: 8
Mix Routing:
- 1x Main LRC
- 2x Bus
- 1x FX Return
Presets: Yes
Display: Main Display: 4.3" Touchscreen
Faders & Level Adjustment: 12 Fader
Meters: 12x LED

Signal Processing
Gain/Trim Range: Up to +86 dB
Solo/Mute: Solo, Solo-in-Place/AFL, Mute, PFL per Input Channel
Built-In Effects: 13x Stereo Effect (Type Unspecified)

Digital Audio
Sample Rates: Up to 96 kHz

Performance
Frequency Response: 20 Hz to 20 kHz (at 1 kHz)
Analog Dynamic Range: 125 dB at Min Gain | 115 dB at Min Gain
THD: Mic Input: < 0.002% at Min Gain (+4 dBu)

Connectivity
Analog Inputs:
- 4x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line Input
- 4x 1/4" TRS Balanced/Unbalanced Stereo Line Input
- 4x RCA Coaxial Stereo Line Input
Analog Outputs:
- 2x XLR 3-Pin Balanced Stereo Main Output
- 8x 1/4" TRS Balanced/Unbalanced Stereo Output
Phantom Power: +48 V
USB I/O: 2x USB-C

Recording
Max Multitrack Recording: 18 Tracks
Media Support: SD, USB Drive
Max Media Storage Capacity: 1 GB

Compatibility
OS Compatibility: macOS 15 or Later / Windows 11 or Later
RAM Requirements: 4 GB

Power
Input Power: 100 to 240 VDC

Physical
Rack Mountable: Yes
Operating Conditions: 32 to 104°F / 0 to 40°C
Dimensions: 13.2 x 12.5 x 3.8" / 33.5 x 31.8 x 9.7 cm
Weight: 8.6 lb / 3.9 kg
1x MGX12 con interfaccia audio (Nero)
1x cavo di alimentazione
