EOS C200 - CanonEAN  4549292089806

Camera
Image Sensor Sensor: Super 35mm type CMOS
Total pixels per sensor : Approx. 9.84 megapixels (4206 x 2340)
Effective pixels per sensor:
° Approx. 8.85 megapixels (4096 x 2160): When 4096 x 2160 or 2048 x 1080 is selected as the resolution
° Approx. 8.29 megapixels (3840 x 2160): When 3840 x 2160 or 1920 x 1080 is selected as the resolution
Dynamic Range : 13 Stops (Canon Log3)

Image Processor
Type Dual DIGIC DV6

Lens
Lens Mount : Canon EF Mount
Lens Magnification Factor (for EF Mount lenses, including Cinema Primes)
° At 4096 x 2160 or 2048 x 1080 resolution: Actual focal length x approx. 1.460
° At 3840 x 2160 or 1920 x 1080 resolution: Actual focal length x approx. 1.534
Changeable Lens Mount: Yes, mount change to PL mount possible via Canon Service centre (Paid for service)
Peripheral illumination correction: Yes with compatible lenses
ND filter: Clear, 2, 4 ,6, 8, 10-stop
Focus control Manual via lens, manual via RC-V100 Auto Focus (Dual Pixel AF Approximately 80%(vert.),80%(horiz.))
Iris control Manual Via camera body or RC-V100, fine, 1/2 or 1/3 step increments, Auto (with compatible lenses), Push Auto Iris
Image stabilization system Depends on lens used

Recording
RAW Recording: options RAW (Cinema RAW Light)
Internal Recording: Cinema RAW Light, MP4
Recording time (Cfast 2.0card) 128GB card 15 Mins (4K Cinema RAW Light 1Gbps VBR)
Recording time (SD Card) 128GB card 110 mins (MP4, 150Mbps) 485Mins (MP4, 35Mbps)
Recording Formats Cinema RAW Light, (Cfast 2.0) MP4 XF-AVC (SD card. XF-AVC1)
Recording Frame Rate (1) 59.94 Hz mode (59.94P/29.97P/23.98P)
(2) 50.00 Hz mode (50.00P/25.00P)
(3) 24.00 Hz mode (24.00P)
Slow/Fast motion: YES
Interval Record: YES
Frame Record: YES
Pre Record (cache record): YES, 3 seconds
Relay Recording: YES, SD Card recording only
Double Slot (simultaneous) Recording YES, SD Card recording only
Scan Reverse: NO
HD-SD conversion: NO
Photo storage media: SD Card

Photo Recording Size
° 2048×1080 (when video image resolution is 4096×2160/2048×1080)
° 3840×2160 (when video image resolution is 3840×2160)
° 1920×1080 (when video image resolution is 1920×1080)

System
Wave Form Monitor : YES
Colour Bars: YES, SMPTE / EBU / ARIB
Peaking: YES
Zebra: YES. Zebra 1 Level 5 5% to 95 5% in 5 percentage point intervals (70 5%) - Zebra 2 Level: 0% to 100% in 5 percentage point intervals (100%)
Markers: YES, Centre, Horizontal, Grid Aspect Ratio(4:3 / 13:9 / 14:9 / 16:9 / 1.375:1 / 1.66:1 / 1.75:1/1.85:1 / 1.90:1 / 2.35:1 / 2.39:1 / Custom), Safe Area (80% / 90% / 92.5% / 95%)

EVF
Built- In EVF: YES. 1.77M dots
Optional EVF Accessory: Canon EVF-V70 (Also requires CL-V2 bracket)

Display Panel
Display Panel : 4 inch/10.1cm diagonal LCD Monitor. Touch panel. Approx., 1.23M dots

Inputs/Outputs
Audio in XLR x2, 3.5mm Audio, AES/EBU digital or Analog Audio input, Line, Mic, +48V Phantom Power supported
Headphone output YES
HDMI YES, HDMI 2.0, output only. Max. output resolution 3840 x 2160.Timecode out compatible
USB YES. Mini-B Hi-Speed USB
3G/HD-SDI output YES x 1.BNC jack
Video [HD]:SMPTE 292. [3G]:SMPTE 424, SMPTE 425
Audio [HD]:SMPTE ST 299-1. [3G]:SMPTE ST 299-2, Output impedance 75 , Output signal level 0.8 Vp-p
Time code: NO
Genlock: NO
Synch: NO
Component out: NO
AV terminal: NO
DC Output: NO

Power
DC input: YES, 14.4V DC (Battery), 16.7V DC (DC-In)
Power Consumption 50.00P: Cinema RAW Light/MP4, 18.5W (Approx.)
Continuous Recording Time (battery) BP-A30 (3100mAh) 130 Min (Approx.) BP-A60 (6200mAh) 280 Mins (Approx.)

Cinema Raw Light/4096 x 2160 or MP4/3840 x 2160 recording
Remote Control Terminal : YES, 2.5mm proprietary connector
Wireless Control Terminal Built-in Wi-Fi. FTP and Browser Remote/Preview
Lens terminal: NO
Ethernet terminal: YES. FTP CAPABLE, MP4 files only
Video connector (For Monitor or EVF) YES, Canon proprietary connection
Misc.
Tally lamp: YES
Custom Dial: YES
