MinFerno - Glensound
Apparecchiature Audio > Postazioni cronista
€ 2.026,94 + Iva
€ 2.472,87 Ivato
BONIFICO BANC MERCE PRONTA / CARTA DI CREDITO / FINANZIAMENTO
Adcom - Glensound
Nuovo
Disponibile in 7 gg
Descrizione articolo
MinFerno è una versione nuova, più piccola e ancora più facile da usare del nostro eccezionalmente popolare box di commento audio di rete Inferno.
MinFerno è progettato per essere utilizzato da un singolo commentatore / annunciatore e, come il suo fratello maggiore Inferno, fornisce il miglior amplificatore per microfono commentario e un circuito limitatore del compressore per un suono straordinario.
Il MinFerno è facile da usare per i commentatori che preferirebbero parlare del gioco piuttosto che capire come funziona l'attrezzatura. È costruito secondo i nostri standard rigorosi, robusti e robusti per renderlo un'apparecchiatura di trasmissione affidabile per i tecnici impegnati.
MinFerno è progettato per essere utilizzato da un singolo commentatore / annunciatore e, come il suo fratello maggiore Inferno, fornisce il miglior amplificatore per microfono commentario e un circuito limitatore del compressore per un suono straordinario.
Il MinFerno è facile da usare per i commentatori che preferirebbero parlare del gioco piuttosto che capire come funziona l'attrezzatura. È costruito secondo i nostri standard rigorosi, robusti e robusti per renderlo un'apparecchiatura di trasmissione affidabile per i tecnici impegnati.
AUDIO INPUT
Input Type: Neutrik 3 pin XLR
Input Impedance: Mic: 2k4
Line 100k
Equivalent Input Noise: 127dBu (22Hz-22KHz) RMS A weighted Terminated with 300 Ohms
Frequency response: Mic -2dBu @25Hz flat @50Hz till 22kHz (+/- 0.25dBu).
Line flat till 22kHz
Distortion at +8dBu: 100Hz = 0.023%
1kHz =0.012%
10kHz = 0.014%
Line Up Gains: Dynamic Mic: 58dB
Mic + Phantom Power: 35dB
Line: 0dB
Gain Range: Mic: -30 to +15dB
Line: +/-15dB
Max Input Before Clipping (@line up):
Dynamic Mic: +10dBU,
Mic+phantom: +18dBu
Line: +18dBu
HEADPHONES
Headphone Impedance: 16-1000 ohm (auto output level to match impedance)
Headphone Noise: -76.6dB @ line up (residual noise)
Headphone Frequency Response: >-0.1dB 22Hz to 22kHz
Headphone THD + Noise (Ref +8dB): 0.008% @ 1kHz
Connection: 6.35mm & 3.5mm stereo jack plugs
Headphone Volume Pot Range: +10dB to Off (can be configured +10dB to -30dB)
Maximum Headphone Output: +16.8dB into 600 Ohms
DANTE/AES67 NETWORK INTERFACE
Physical: 2 x Neutrik Ethercons Cat6 RJ45s & 2 x SFP slots
Type: Fully redundant Primary & Secondary circuits
Sample Frequency: 48K
Resolution: 24 Bit
Control & Routing: Via Free Dante Controller
AES67: Compliant (Can be configured for AES67 via Dante® controller)
NETWORK TYPE: Gigabit Ethernet
POWER
PoE: Can be powered by PoE on either Copper network interface
PoE: Complies to IEEE 802.3af-2003 classification class 0
DC Input: 2.5mm Barrel, Centre +Ve, 9 - 15 Volts
Consumption: Front Panel Power On LED: Bright Blue
Rear Panel Power On Indicators: 1 green LED showing presence of each of the above power sources
PHYSICAL
Size: 144 x 179 x 76mm (WxDxH)
Weight: 1.01Kg (2lb3oz)
Mechanics: All aluminium construction, anodised and laser etched, powder coated sides
Shipping Carton: Rugged Export Quality cardboard carton 610 x 420 x 170mm (WxDxH)
Shipping Weight: 2.5kg
ENVIRONMENTAL
Operating Temperature: 0 to +50°C (32 to 122°F)
Storage Temperature: -20 to +70°C (-4 to 158°F)
Relative Humidity: 0 to 95% non-condensing
INCLUDED ITEMS
Handbook: Physical A4 (Soft copy can be downloaded)
Mains Cable: UK & EU only, 2 metre mains plug to IEC
RJ45 Network Cable: 1 of 2 Metre
OPTIONAL ITEMS
Carrying Case: Polypropylene Carrying Case
SFP Fibre Modules: Multi Mode, Single Mode and Bi-directional on single Fibre available
External DC Power Supply: Switch mode (100 - 250VAC) desktop style with IEC mains input & 1.5 metre DC output cable
