Device to send HDMI 18G & IR signals up to 50m by means Cat.6 cable.
Estends 4K HDMI 18G signals up to 50m distance using a normal, standard CAT 6 cable
Support resolutions up to 3840x2160@60Hz 4:4:4 8bit, with support HDR
Support audio formats llossless multi channel like DolbyTrueHD and DTS-HD
Out HDMI loop through on the transmitter good for a local screen
PoC (Power over Cat.6), needs of one only power supply

Specifications
======================
Standard Interface: HDMI 2.0
Bandwhidt : 18Gbps
Max Distance : 50m (164.04ft) - Cat.6/7, 30m (98.42ft)- Cat.5e
Max Resolution : 3840x2160@60Hz 4:4:4 8bit
Support HDCP: 2.2
EDID : Pass Through
Support Audio: Up to 7.1 (loop through)
Support IR: 20-60kHz
Serial interface : supported
Chipset: Transmitter: SIL9396 / Receiver: SIL9630

Particular functions:
PoC (Power over Cat.6)
IR pass through
Loop Out

Connectors
Input Transmitter: HDMI Tipo A 19pin (Female), Micro-USB (Female), DC12V
Out Transmitter: HDMI Tipo A 19pin (Female), RJ45 (Female), IR (Female)
Input Riceiver: RJ45 (Female), IR (Female), Micro-USB (Female)
Out Riceiver: HDMI Tipo A 19pin (Female)
Power supply : 5.5/2.1mm

Dimensions (ca.) LxPxA:
Trasmettitore: 70x97x15mm (2.76x3.82x0.59in)
Riceiver: 70x97x15mm (2.76x3.82x0.59in)
Net weight: Transmitter: 0.156kg (0.34lb)
Receiver : 0.151kg (0.33lb)
Operative Temperature : 0°C - 40°C (32°F - 104°F)
Consumption : 12VDC 1A
Color: Black

Varie
Tipo Confezione: Scatola in cartone
Dimensione Confezione: 220x130x70mm (8.66x5.12x2.76in)
Peso Lordo: 0.605kg (1.33lb)
Garanzia (Anni): 2
Certificazioni: CE, FCC, RoHS, REACH & California Proposition 65

In the box
Transmitter
Receiver
Power Supply12VDC 1A Multi-country (UK, EU, US & AUS)
Transmitter IR
Receiver IR
Manual

Transmitter
Receiver
Power Supply12VDC 1A Multi-country (UK, EU, US & AUS)
Transmitter IR
Receiver IR
Manual
